Notes on pyjetty structure

Back to table of Contents

• plots found in performance/mc_projections_both, performance/mc_projections_det, and performance/mc_projections_truth are put together in: analysis/user/rey/plotting_utils.py

the function plot_obs_projection gets called in plot_obs_projections (note s at the end) a couple of times.

• plots found in main/Unfolded_... are put together in: analysis/user/substructure/roounfold_obs.py

• prior scaling is done in: /home/rey/pyjetty/cpptools/src/rutil/rutil.cxx

Closure Tests:

• closure tests done in: analysis/user/substructure/roounfold_obs.py in the function unfolding_checks

  • refolding test: refolding_test
  • and statistical closure test: statistical_closure_test
  • shape closure test done in function: shape_closure_test
    • the shape closure test uses the function scale_by_prior defined in analysis/base/analysis_utils.py
  • thermal closure test: plot_thermal_closure_test

Response-Matrix Slices:

• response-matrix slices plotted in: analysis/user/substructure/roounfold_obs.py (see function plot_RM_slices)

Bayesian Unfolding

Done in analysis/user/substructure/roounfold_obs.py. Search the code for the line that reads unfold_bayes = ROOT.RooUnfoldBayes(response, hData, i). The unfolded (truth) distribution is then obtained by doing: hUnfolded = unfold_bayes.Hreco(self.errorType). See documentation for these functions here. The Bayes RooUnfold source code is here. This class inherits from here. Additional notes are here and a practical example is here.

TVectorD PbarCi(_nc);

for (Int_t kiter = 0 ; kiter < _niter; kiter++) {

	if (verbose()>=1) cout << "Iteration : " << kiter << endl;

    	// update prior from previous iteration
    	if (kiter>0) {
      		_P0C = PbarCi;
      		_N0C = _nbartrue;
    	}

    	for (Int_t j = 0 ; j < _ne ; j++) {
      		Double_t Uj = 0.0;
      		for (Int_t i = 0 ; i < _nc ; i++)
        		Uj += PEjCi(j,i) * _P0C[i];
      		_UjInv[j] = Uj > 0.0 ? 1.0/Uj : 0.0;
    	}

    	// Unfolding matrix M
    	_nbartrue = 0.0;
    	for (Int_t i = 0 ; i < _nc ; i++) {
      		Double_t nbarC = 0.0;
      		for (Int_t j = 0 ; j < _ne ; j++) {
        		Double_t Mij = _UjInv[j] * PEjCiEff(j,i) * _P0C[i];
        		_Mij(i,j) = Mij;
        		nbarC += Mij * _nEstj[j];
      		}
      		_nbarCi[i] = nbarC;
      		_nbartrue += nbarC;  // best estimate of true number of events
    	}

    	// new estimate of true distribution
    	PbarCi= _nbarCi;
    	PbarCi *= 1.0/_nbartrue;

A breakdown of what’s happening in the code above is represented below:

Embedding

See function analyze_event in user/substructure/process_mc_base.py.

The embedding is done right after a comment that reads # If Pb-Pb, construct embedded event (do this once, for all jetR)
